xDuoo MH-02 / MH 02

USB DAC decoding convenient connection

Support the USB decoding of computer, cellphone (ios/Android) tablet, HIFI player and other devices. Support up to PCM32Bit/384kHz, DSD256, MQA32Bit/384kHz.

CS43131 DAC CHIP

The DAC chip uses the CS43131 chip known for its extremely low noise and higher resolution resulting in superior decoding performance.

Transistor For Class A Amplifier - Output Power Up To 1300 MW

Adopt transistors for class A buffer, output power up to 1300mW , can easily drive many kind earphones.

Gain switch to set gain according to the headphones

Set the two-gear gain and gently press it to achieve the matching of different impedance headphones, avoiding the phenomenon of excessive or insufficient driving force.

Line out can be used as preamplifier

It has one line output, through the tube, and controlled by volume. It can be used as the Pre-amplifier of all kinds of audio amplifier or active speaker, and improve the sound quality of audio amplifier or active speaker.

High-grade audio capacitors

Adopt the Japanese ELNA capacitance as the coupling capacitance have transparent and sweet sound. Adopt the Japanese RUBYCON capacitance as the main filter capacitance, have smooth and warm sound, and splendid high frequency.

Tube Amplifier

Adopt double 6J1 tube for pre-amp making voice sweet and exquisite.

Specification:

Power Supply: DC12V/2A Compliant OS: WINDOWS, LINUX, MAC OS X, I0S, ANDROID SYSTEM Sampling Rate Support: PCM 16-32BIT/44. 1K- 384KHZ, DSD64-256. Output Power: 1300MW(32 LOAD) Frequency Response: 10HZ~60KHZ(0.5DB) Gain: +12/18DB THD+N: 0.8% (1KHZ,32 LOAD) S/N: 118DB Crosstalk: 70DB Size: 12 X 7.8 X 4.0CM Weight: 0.35KG

Whats In The Box

1. MH-02
2. Power Cable
3. User Manual
4. Brand Card
