Shanling UA Mini

Control Your Playback With Eddict Player Application

Shanling UA-Mini has complete integration with Shanling’s very own Eddict Player application. It brings you smart playback control, fine-tune the volume, switch the digital filters, adjust the gain filters, channel balance, and other settings. Personalize your experience with the UA Mini using the Eddict Player.

Enjoy True High-Fidelity Audio Processing

Shanling UA-Mini comes equipped with Cirrus Logics' advanced CS43131 DAC chipset. It is a 32-bit DAC that provides exceptional high-resolution audio signal processing characteristics, delivering high SNR, DNR, and ultra-low THD+N performance. It packs in true high-fidelity audio signal processing with support for 32-bit/384kHz PCM and native DSD256 audio signals.

Powerful Output With Dedicated Amp Section

Shanling has equipped the UA-Mini with a dedicated amp section consisting of dual SGM8262 chips. It produces a strong output reaching about 260mW per channel at 16Ω and about 205mW per channel at 32Ω of impedance load.

Supports UAC1.0 Mode

Dominate the battlefield with the support of UAC1.0 mode on the Shanling UA-Mini. It enables high-resolution audio signal processing on the Nintendo Switch gaming console. Enjoy high-quality audio while playing your favourite video games on the Nintendo Switch gaming console.

LED Indicator That Denotes Active File Bitrate

Shanling UA-Mini features a multi-colour LED indicator that glows with different colours based on the active file’s bitrate. It glows Blue for 44.1~48 kHz, Green for 88.2~96 kHz, Yellow for 176.4~192 kHz, Purple for 352.8~384 kHz, and White for native DSD audio signals.

Specifications:

Weight: about 8.4g

Headphone jack: 3.5mm

Plug: Type-C USB cable plug

USB chip: Savitech SA9312

DAC chip: Cirrus Logic cs43131

Op amp chip: SGM8262-2

PCM specification: 44.1-384kHz/32bit

DSD specification: DSD64-DSD256

Output power: (32OhmTHD+N<1%)L+R=205mW+205mW

Output power: (16OhmTHD+N<1%)L+R=260mW+260mW
