Shanling M1 Plus

The Shanling M1 Plus, powered by the Ingenic X2000 processor and the latest MTouch system, delivers a comprehensive range of features in a compact package. This device supports Bi-directional Bluetooth V5.2, two-way USB connection, 3.5mm Coaxial SPDIF Out, and Wi-Fi connectivity for DLNA/Airplay, ensuring smooth local playback with expandable MicroSD card support.

Encased in a sleek aluminum and glass body, the M1 Plus reflects the bold, modern design introduced with the M5 Ultra. Despite its compact size of just 86 x 61 x 17mm and a weight of only 116 grams, it boasts a 3.2-inch screen that strikes the perfect balance between touch controls and portability for daily use.

The audio circuit is centered around the ESS ES9069Q DAC, delivering dynamic and detailed sound. It is supported by dual SGM8262 amplifiers, providing up to 660 mW of output power at 32 Ohms, capable of driving even full-size audiophile headphones. With both 4.4mm balanced and standard 3.5mm outputs, the M1 Plus ensures compatibility with a wide range of earphones and headphones.

Specification

Dimensions: 86 x 61 x 17 mm
Weight: 116 g
DAC: ESS ES9069Q
Amplifier: Dual SGM8262
Platform: Ingenic X2000
System: MTouch developed by Shanling
Screen: 3.2-inch 320 x 480 Touchscreen
Memory: MicroSD card slot
Hi-Res Support: PCM 32 bit / 768 kHz & DSD512
Wi-Fi: 2.4/5G, supporting DLNA, Airplay and OTA Updates
Bluetooth: Upgraded 5.2 with Bi-Directional support of LDAC, aptX HD, aptX, AAC
Companion app: Eddict Player app through SyncLink
Connectors: 3.5mm Single-Ended, 4.4mm Balanced, USB-C
Battery: 2100 mAh
Battery life: Up to 12.5 hours

Single-Ended Output:

Power: 195 mW @ 32 Ohm
THD+N: 0.0007%
Channel Separation: 74 dB
SNR: 122 dB
Output impedance: 0.6 Ohm

Balanced Output:

Power: 660 mW @ 32 Ohm
THD+N: 0.0007%
Channel Separation: 100 dB
SNR: 122 dB
Output impedance: 1.2 Ohm
