JCALLY JA56

Realtek ALC5686

JA56 use Realtek ALC5686 DAC chip. The chip built-in DCDC power management audio CPU and ARM CPU. The chip with high operating frequency and wide power input characteristics. Support UAC1.0/2.0 and LPM/L1 feature's ADC3.0.

Support USB2.0HS/FS model and filled with 256kB storage.Built-in clock vibrator circuit with audio balance adjustment, bass enhancement, echo elimination.Support PCM 16/20/24/32 bits data length and 8K~383K digital - to - analog conversion and analog - to - digital conversion high performance.

It has a clock rate of up to 2MHz, an internal G type earphone amplifier and built-in intelligent hot-swap detection and elimination.It has the advantages of low power consumption, good compatibility and so on.

Mini Portable Lightweight Experience

Small in size, light in weight, good looking. Small and portable. Enjoy HIFI loseless music at any time.

Enjoy Nature of Sound

Restore the sense of music presenece. Do not need to install driver, plug and play, lossless transmittance, pleasant sound quality.

Specification:

Brand: JCALLY

Product name:JA56 digital amplifier adapter TYPE C to 3.5mm

DAC:ALC5686

Sampling tate:32bits-384KHz

THD+H:-95dB

Support:USB Exclusive

SNR/DNR:124dB/-113dB

Shell:Aluminum space

NET weight:4g+-0.3g

Color:Matte Silver
